Wraptor A6200 Wrap Printer Applicator with Wi-Fi and Software

Order Reference: A6200-EUB-WIFI

Stand Alone Printing: Stand-alone & Peripheral
Application(s): Wire and cable labelling
Max. Label Width (mm): 25.40 mm
Recommended Usage per Day: 1000
Continuous vs Die Cut Labels: Die-cut
Colour Capability: Monocolor
Resolution (dpi): 300 dpi
Print Technology: Thermal Transfer
Warranty: 1 year

Advantages of Wraptor A6200

Brady Printer Wraptor A6200 | Wrap Printer Applicator overview

Get automated efficiency with the Wraptor™ A6200 Wrap Printer Applicator. Print, wrap and apply in just seconds. Ideal in smaller workspaces and cellular manufacturing.

Prints and applies labels to wires in less than seven seconds.
Offers fast material changeovers for added efficiency.
Full-colour responsive touch screen and an icon-based user interface for ease of use.
Enhanced connectivity with Wi-Fi, three USB ports and 32GB of internal memory to store file jobs.
Compatible with the Wraptor™ A6200 Bulk Label Roll Adapter, A62 Series label rolls and BA62 Series bulk label rolls.
Ships with Brady Workstation Product and Wire ID Software Suite with built-in templates for fixed text or free-form label design options.

Specifications

Key Characteristics:

Description	Value
Article Number	176479
Order Reference	A6200-EUB-WIFI
Total Qty per Pack	1 Piece(s) / Pack
Minimum Order Quanitity	1
Application(s)	Wire and cable labelling
Quantity	1
Brand	Brady®
Trade Name	Wraptor™ A6200
Country of Origin	MY

Dimensions

Description	Value
Size - Width (mm)	224.79 mm
Size - Height (mm)	210.82 mm
Size - Depth (mm)	297.18 mm
Weight (kg)	4.08 kg
Max. Wire/Cable Diameter (mm)	6.35 mm
Min. Wire/Cable Diameter (mm)	1.19 mm
Minimum Label Height (mm)	19.05 mm
Min. Label Width (mm)	12.70 mm
Wire Diameter Range (mm)	1,19 mm to 6,35 mm
Dimensions	224,79 mm (W) x 210,82 mm (H) x 297,18 mm (D)

Material Characteristics:

Description	Value
Materials Supported	Nylon Cloth, Self-laminating Vinyl

Product Features:

Description	Value
Battery Type	No Battery
Calibration	No
Connectivity Options	Ethernet, USB, Wi-Fi
Display Type	Colour LCD Touchscreen
Hardware Options	Bulk Label Roll Adapter, Rewinder
Internal Memory Capacity	32 GB, expandable through USB
Operating Humidity Range	10%-80% (non-condensing)
Operating System	Windows® 10, Windows® 7, Windows® 8
Operating Temperature	15°C - 32°C
Stand Alone Printing	Stand-alone & Peripheral
Power Source	AC Adaptor
Power Supply Voltage	110 - 240 V
Storage humidity	20%-80% (non-condensing)
Storage Temperature	0°C - 60°C

Printing Specifications:

Description	Value
Print Technology	Thermal Transfer
Print Speed (mm/sec)	38.10 mm/s
Colour Capability	Monocolour
Resolution (dpi)	300 dpi
Display Resolution	1024 x 800 pixels
Max. Label Width (mm)	25.40 mm
Recommended Usage per Day	1000
Max. Print Width (mm)	25.40 mm
Max. Print Length (mm)	31.75 mm
Maximum Label Height (mm)	31.75 mm
Application Cycle Time	7 seconds
Hours of Operation	8 hours/5 days

Compatibility:

Description	Value
Continuous vs Die Cut Labels	Die-cut
Software Compatibility	Brady Workstation, CodeSoft, Windows based driver for 3rd party software use
B- Numbers supported	B-417, B-427, B-499
Compatible Media	A62-, BA62-
Min. Label Length (mm)	31.75 mm

What's Included:

Description	Value
Includes	(1) Brady Workstation Product and Wire ID Suite Booklet (Download Code Inside), (1) Power Cord and AC Adapter, (1) Printer Applicator A6200, (1) Printer Ribbon A62-R4300, (1) Quick Start Guide, (1) Roll of Vinyl Clear/White Labels A62-3-427, (1) USB Cable
Warranty	1 year

Compliance:

Description	Value
UNSPSC	45101519
RoHS Compliance Status	Compliant with Directive 2011/65/EU and 2015/863
REACH SVHC Status	Part contains an SVHC
REACH Candidate List Date	14 June 2023
Safe Use Instructions	SUI_Systems.pdf
