Portable Label Printer M410, EU with Brady Workstation Suite
Order Reference: M410-KIT-EU-BWS
- Stand Alone Printing: Stand-alone & Peripheral
- Continuous vs Die Cut Labels: Continuous and Die-cut
- Application(s): Asset tracking, Component and equipment labelling, Data and telecommunications labelling, Electrical labelling, Facility identification, General identification, Inventory and inspection labelling, Laboratory labelling, Wire and cable labelling
- Max. Label Width (mm): 25.40 mm
- Recommended Usage per Day: 250
- Resolution (dpi): 300 dpi
- Print Technology: Thermal Transfer
- Colour Capability: Monocolor
- Warranty: 2 years
Advantages of Brady M410
Specifically engineered for premium 25.40 mm printing, the M410 Label Printer is an everyday workhorse for DataCom, electrical and lab professionals.
- Print pre-sized or continuous labels up to 25.40 mm wide with edge-to-edge printing
- 110+ hassle-free drop-in cartridges with 12+ purpose-built materials to take on whatever your work demands
- Get seamless cartridge changes with an easy-swap locking mechanism while a window in the door allows you to easily remember what's installed
- Create and print two ways — the intuitive QWERTY kepad or a PC
- Designed to withstand 1.2 m drops and challenging work environments
- Enhanced exterior colouring for jobsite visibility
- Ships with a licence for the Brady Workstation suite of your preference: Product & Wire Identification, Safety & Facility Identification, or Lab Identification, enabling easy creation of a wide range of labels and signs.
- Backlit LCD graphics display for easier labelling in low-lit areas
Brady M410 Label Printer
Specifications
Key Characteristics:
| Description | Value |
|---|---|
| Article Number | 322718 |
| Order Reference | M410-KIT-EU-BWS |
| Total Qty per Pack | 1 Kit / Box |
| Minimum Order Quanitity | 1 |
| Application(s) | Asset tracking, Component and equipment labelling, Data and telecommunications labelling, Electrical labelling, Facility identification, General identification, Inventory and inspection labelling, Laboratory labelling, Wire and cable labelling |
| Quantity | 1 |
| Brand | Brady® |
| Trade Name | M410 |
| Country of Origin | MY |
Dimensions
| Description | Value |
|---|---|
| Size - Width (mm) | 152.40 mm |
| Size - Height (mm) | 292.10 mm |
| Size - Depth (mm) | 88.90 mm |
| Weight (kg) | 1.18 kg |
| Display Size | 34.92 x 50.80 mm |
| Min. Label Width (mm) | 6.10 mm |
| Dimensions | 152,40 mm (W) x 292,10 mm (H) x 88,90 mm (D) |
Material Characteristics:
| Description | Value |
|---|---|
| Materials Supported | BradyGrip® Polyester, FreezerBondz™ Polyester, Heat-shrink Polyolefin, Metallised Polyester, Nylon Cloth, Paper, Polyester, Polypropylene, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, Vinyl, Vinyl Cloth |
| Colour | Yellow, Black |
Product Features:
| Description | Value |
|---|---|
| Battery mAh Rating | 1200 mAh |
| Bar Code Type | Code 128, Code 39, More through Brady WorkStation |
| Auto Shut Off | 10 minutes, User Configurable |
| Battery Type | Rechargeable NiMH Battery |
| Battery Weight (metric) | 254.00 g |
| Built-in Symbols | 480 |
| Language Support | Bulgarian, Chinese (Traditional & Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French, German, Hungarian, Italian, Japanese, Norwegian (Bokmål), Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish (Mexico), Swedish, Turkish |
| Calibration | Automated through Smart Cell |
| Connectivity Options | USB |
| Custom Labels Available | No |
| Cutter | Single Hand Manual Actuate, Straight Cut, With label retention |
| Display Type | Monocolour LCD Screen |
| How Is Battery Shipped | Shipped installed in equipment |
| Interface Type | Full QWERTY Keyboard, PC |
| Internal Memory Capacity | 48 MB (stores up to 25,000 labels) |
| Barcode Symbologies - 2D | More through Brady Workstation |
| Keyboard Type | QWERTY |
| Operating Humidity Range | 20%-90% (non-condensing) |
| Operating Temperature | 4°C - 43°C |
| Stand Alone Printing | Stand-alone & Peripheral |
| Power Source | AC Adaptor, Rechargeable Battery |
| Power Supply Voltage | 110 - 240 V |
| Printing Wizards | 66 Block, Breaker Box, DesiStrip, Flags, General, Patch Panel, Terminal Block, Wire Wrap |
| Recharge Time | 4 hours |
| Shipped With Battery | Yes |
| Storage humidity | 10%-90% (non-condensing) |
| Storage Temperature | -18°C - 43°C |
| Charging Times | Charging over battery charger (0 - 100%) 4h |
Printing Specifications:
| Description | Value |
|---|---|
| Print Technology | Thermal Transfer |
| Print Speed (mm/sec) | 33.02 mm/s |
| Printing Functions | Auto Format, Banner, Date/Time Stamp, Fixed Length, Mirror, Print Preview, Reverse, Serialisation, Vertical |
| Colour Capability | Monocolour |
| Resolution (dpi) | 300 dpi |
| Display Resolution | 240 x 160 pixels |
| Max. Label Width (mm) | 25.40 mm |
| Max. Liner Width (mm) | 33.27 mm |
| Recommended Usage per Day | 250 |
| Max. Print Width (mm) | 25.40 mm |
| Max. Print Length (mm) | 990.60 mm |
| Text Sizes (pt) | 4 - 103 pt |
| Font Styles | Brady Alpine, Brady Fixed Width |
| Symbol Categories | Arrows, Datacom, Electrical, Exit, Fire Safety, First Aid, GHS/CLP, Greek, Home Electrical, HSID, International, Laboratory, Mandatory, Miscellaneous, Packaging, Personal Protective Equipment, Prohibition, Public Information, Safety, Warning, WHIMIS |
| Number of Stock Parts | 110+ standard parts |
| On Screen Indicators | Battery Life, Ribbon and label part number recognition, Supply Remaining |
| Print Rotation | Yes |
| Drop Test | Resistant to 1.2 metre drops |
| Serialisation | Simple & Simultaneous & Single Advanced & Multiple Advanced |
| Smart Cell | Yes |
Compatibility:
| Description | Value |
|---|---|
| Continuous vs Die Cut Labels | Continuous and Die-cut |
| Software Compatibility | Brady Workstation, Windows based driver for 3rd party software use |
| B- Numbers supported | B-342, B-403, B-412, B-414, B-417, B-422, B-423, B-425, B-427, B-428, B-430, B-483, B-483A, B-488, B-498, B-499, B-581, B-584, B-595, B-7425, B-7641 |
| Compatible Media | M4-, M4C- |
| Min. Label Length (mm) | 6.10 mm |
| Min. Liner Width (mm) | 20.65 mm |
What's Included:
| Description | Value |
|---|---|
| Includes | This M410 Printer ships in a hardcase with a rechargeable NiMH Battery Pack, an AC Adapter, B-595 Vinyl label Cartridge, a Magnet, a Utility Hook, a Quick start Guide, a USB Cable, a licence for Brady Workstation Software suites and a USB Flash Drive with Driver and User Manual. |
| Warranty | 2 years |
Compliance:
| Description | Value |
|---|---|
| UNSPSC | 45101520 |
| RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
| REACH SVHC Status | Part contains an SVHC |
| REACH Candidate List Date | 23 January 2024 |
| Approval/Compliance | CE, UKCA |
| Safe Use Instructions | Sistem_SUI.pdf |
