Industrial label printer BradyPrinter i7500 300 dpi - EU with Auto cutter + Brady Workstation Suite
Order Reference: I7500-300-C-EU-BWS
- Connectivity Options: Bluetooth, Ethernet, USB, Wi-Fi
- Min. Label Width (mm): 4.01 mm
- Application(s): Asset tracking, Barcode labelling, Circuit board labelling, Data and telecommunications labelling, Electrical labelling, General identification, Inventory and inspection labelling, Laboratory labelling, Solar Panel labelling, Tamper Indicating Labels, Warehouse marking, Wire and cable labelling
- Colour Capability: Monocolor
- Max. Label Width (mm): 108.97 mm
- Max. Print Length (mm): 18.29 m
- Resolution (dpi): 300 dpi
- Warranty: 1 year
Advantages of BradyPrinter i7500
i7500 Industrial Label Printer Overview Video
High-performance 76.2 mm core label printing the way you never thought possible.
Get 40-second part changeovers with no adjustments, no trial-and-error print tests and no wasted labels. LabelSense(TM) Technology allows the printer, Brady i75-Series materials and Brady software to communicate; automating and eliminating tedious adjustments and label-wasting tasks.
- No need to set print speed, heat, offsets, sensor mode or sensor location — i7500 does it automatically without wasteful trial-and-error print tests
- No need to calibrate wasted blank labels — i7500 detects the part size and spacing, and prints on the very first label
- i75-Series ribbons auto-center with the ink always facing the correct way; the i7500 will warn you if the ink type is a mismatch with the installed label material
- Over 4,000 stock i75-Series label parts and ribbons in 80+ materials operate in full smart-mode functionality
- Manual 76.2 mm core label rolls and 25.4 mm core ribbons will also function in full manual mode where the operator makes necessary adjustments for print settings, sensor adjutments, label calibration and correct ribbon pairing
- Brady WorkStation software Suite (included) auto-detects the installed part for driverless 1-click setup and label file creation; or use Win driver if using non-Brady software
- 300 dpi print resolution for day-to-day printing, or user can quickly field-exchange with optional 600 dpi printhead with no calibration or firmware update required
- Auto Cutter configuration ships with the Heavy-Duty Guillotine Cutter accessory installed for full cut-through after job, after label row, after set or no cut at all
Specifications
Key Characteristics:
| Description | Value |
|---|---|
| Article Number | 323188 |
| Order Reference | i7500-300-C-EU-BWS |
| Total Qty per Pack | 1 Piece(s) / Box |
| Minimum Order Quanitity | 1 |
| Application(s) | Asset tracking, Barcode labelling, Circuit board labelling, Data and telecommunications labelling, Electrical labelling, General identification, Inventory and inspection labelling, Laboratory labelling, Solar Panel labelling, Tamper Indicating Labels, Warehouse marking, Wire and cable labelling |
| Quantity | 1 |
| Brand | Brady® |
| Trade Name | i7500 |
| Ribbon Series | i75-R4300, i75-R4400-BL, i75-R4400-GR, i75-R4400-RD, i75-R4400-WT, i75-R4500-BL, i75-R4500-RD, i75-R4500-SV, i75-R4900, i75-R6000, i75-R6200, i75-R6300, i75-R6400, i75-R6600, i75-R6700, i75-R6800 |
| Country of Origin | MY |
Dimensions
| Description | Value |
|---|---|
| Size - Width (mm) | 292.10 mm |
| Size - Height (mm) | 370.84 mm |
| Size - Depth (mm) | 530.86 mm |
| Weight (kg) | 18.14 kg |
| Core - Diameter (mm) | 76.20 mm |
| Display Size | 177.80 mm |
| Minimum Label Height (mm) | 3.18 mm |
| Min. Label Width (mm) | 4.01 mm |
| Dimensions | 292,10 mm (W) x 370,84 mm (H) x 530,86 mm (D) |
Material Characteristics:
| Description | Value |
|---|---|
| Materials Supported | Diesel-resistant Heat-shrink Polyolefin Sleeve, Direct Thermal Paper, FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metallic, Non-metal Polyester, Metallised Polyester, Nylon Cloth, Paper, Polyester, Polyethylene Foam Laminate Polyester, Polyethylene Tag, Polyimide, Polypropylene, Polyvinylfluoride, Repositionable Paper, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallised Polyester, Tamper-evident Polyester, Tamper-resistant Metallised Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth |
| Colour | Blue, Grey |
Product Features:
| Description | Value |
|---|---|
| Bar Code Type | Codabar, Code 128, Code 128A, Code 128B, Code 128C, Code 39, Code 39 Full ASCII, Code 93, Code 93 Full ASCII, EAN-13, EAN-13 Extension 2, EAN-13 Extension 5, EAN-8, EAN-8 Extension 2, EAN-8 Extension 5, GS1-128, HIBC, Industrial 2 of 5, ITF-14, JAN-13, JAN-13 Extension 2, JAN-13 Extension 5, JAN-8, More through Brady WorkStation, More through software, UPC-A, UPC-E |
| Auto Shut Off | Yes |
| Battery Type | Coin/Button Cell, Internal, not removable |
| Media Sensor | Black Mark, Continuous, Gap Sensor, Notch |
| Language Support | Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional & Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), German, Hungarian, Japanese, Korean, Norwegian (Bokmål), Polish, Portuguese, Romanian, Russian, Slovak, Spanish (universal), Thai, Turkish, Vietnamese |
| Calibration | Automated with i75-Series Consumables |
| Connectivity Options | Bluetooth, Ethernet, USB, Wi-Fi |
| Custom Labels Available | Yes |
| Cutter | Auto Cutter (cut off), Auto Cutter (perf cut) |
| Display Type | Colour LCD Touchscreen |
| Hardware Options | Cleaning swabs, I/O interface accessory, Narrow width print rollers, Print head (300 dpi), Print head (600 dpi) |
| How Is Battery Shipped | Shipped installed in equipment |
| Interface Type | Touchscreen & PC |
| Internal Memory Capacity | 512 MB RAM, 195 MB IFFS Flash |
| Barcode Symbologies - 2D | Aztec, Data Matrix, GS1 DataMatrix, MicroPDF417, PDF417, QR code |
| Keyboard Type | None |
| Operating Humidity Range | 10%-85% (RH non-condensing) |
| Operating System | Windows® 10, Windows® 11, Windows® 8.1, Windows® Server 2012, Windows® Server 2012 R2, Windows® Server 2016 |
| Operating Temperature | 10°C - 40°C |
| Stand Alone Printing | Mobile device connected, Stand-alone & Peripheral |
| Power Source | Outlet |
| Power Supply Voltage | 100 - 240 V @ 50 - 60 Hz |
| Print Preview Feature | Yes |
| Shipped With Battery | Yes |
| Storage humidity | 15%-90% (RH non-condensing) |
| Storage Temperature | -20°C - 50°C |
| Units | Inches, Millimetres, Points |
| Cut Options Available | Cut at the end of print jobs |
Printing Specifications:
| Description | Value |
|---|---|
| Print Technology | Direct Thermal, Thermal Transfer |
| Print Speed (mm/sec) | 304.80 mm/s |
| Printing Functions | Autocut material (accessory required), Perforation (accessory required), Tear-off print |
| Colour Capability | Monocolour |
| Resolution (dpi) | 300 dpi |
| Display Resolution | 1024 x 600 pixels |
| Max. Label Width (mm) | 108.97 mm |
| Max. Liner Width (mm) | 114.05 mm |
| Max. Print Width (mm) | 105.66 mm |
| Max. Print Length (mm) | 18.29 m |
| Max. Roll Outer Diameter (mm) | 215.90 mm |
| Maximum Label Thickness (mm) | 1.956 mm |
| Hours of Operation | 24 hours/7 days |
| Number of Stock Parts | 4500+ standard parts |
| On Screen Indicators | Bluetooth Status, Data Reception, Digital Clock, Error Messaging, Ethernet Status, i75 Smart material / Manual Material, Label dimensions, Print Job Preview, Ready state, Ribbon and label part number recognition, Supply Remaining, USB Connection, User-defined Printer Name, WiFi |
| Programming Language | ZPL Emulator |
| Smart Cell | Yes |
Compatibility:
| Description | Value |
|---|---|
| Continuous vs Die Cut Labels | Continuous, Die-cut |
| Software Compatibility | Brady Workstation, Windows based driver for 3rd party software use |
| Compatible Media | 2FR-, 2HT-, 2HX-, 2LSZH-, 3FR-, 3HT-, 3PS-, APL-, DR-, DT-, FR-, HCM-, HSNX-, HT-, HX-, i75-, LSZH-, PS-, THT-, THTC-, THTCLP-, THTCLT, THTEL-, THTEP-, THTFP-, THTFT-, THTHD-, THTPNP-, THTRDS-, THTRO-, THTTL-, XTHT- |
| Min. Liner Width (mm) | 9.09 mm |
What's Included:
| Description | Value |
|---|---|
| Includes | This i7500 Printer 300dpi comes in a cardboard box. It ships with a i7500 Heavy Duty Guillotine Auto Cutter, a Cutter tray, a T-20 wrench, a Power cord (EU plug), a USB cable, a license for Brady WorkStation Software Suites and a QuickStart Guide. |
| Warranty | 1 year |
Compliance:
| Description | Value |
|---|---|
| UNSPSC | 45101519 |
| RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
| REACH SVHC Status | Part contains an SVHC |
| REACH Candidate List Date | 07 November 2024 |
| Approval/Compliance | CE |
| Printer can be shipped to | Albania, Andorra, Austria, Bahrain, Belgium, Bosnia and Herzegovina, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Egypt, Equatorial Guinea, Estonia, Finland, Georgia, Germany, Gibraltar, Greece, Hungary, Iceland, Ireland, Israel, Italy, Jordan, Kosovo, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Metropolitan France, Moldova, Monaco, Montenegro, Netherlands, Norway, Poland, Portugal, Qatar, Republic of North Macedonia, Romania, San Marino, Saudi Arabia, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Tunisia, Turkey, United Kingdom, Vatican City |
| Safe Use Instructions | Sistem_SUI.pdf |
| Patent Number | Patent Pending |
Accessories
i7500 Heavy Duty Guillotine Auto Cutter
i7500-ACG-TRAY
i7500 Tear plate for standard configuration
i7500-TEARPL-STD
i7500 Cutter Tray
i7500-CUTTER-TRAY
i7500 Replacement Printhead 300 dpi
i7500-PH-300D
i7500 Print Roller 114 mm
i7500-PR-ROLL-114
i7500 Print Roller 80 mm
i7500-PR-ROLL-80
i7500 Print Roller 50 mm
i7500-PR-ROLL-50
i7500 Print Roller 25 mm
i7500-PR-ROLL-25
I7500 Spare T-Wrench accessory
I7500-T-WRENCH
